Prindle 16 Hull Parts

16 products

    Parts for your Prindle 16 Hull.  Shroud anchor pins, access ports, bow tang, hull plugs and more.

    16 products
    Harken 57mm Ratchet Block - Swivel, Becket, Cam Cleat Murrays Part# 28-2139 Harken 57mm jib block is great for use on almost all Hobie Cat, Nacra and Prindle. Carbo Ratchets allow sailors to hand-hold loaded lines and offer balance between holding power and controlled easing. Specifications Sheave diameter: 2-1/4" Length: 4-15/16" Weight: 9 oz Shackle pin diameter: 3/16" Maximum line diameter: 3/8" Maximum working load: 600 lb. Breaking load: 1500 lb.
    HARKEN 57MM RATCHET BLOCK- SWIVEL, BECKET, CAM CLEAT
    Harken
    PRINDLE 15/16/18 SHROUD ANCHOR PIN
    Misc
    Nylon Port Fastener Kit The Port Nylon Fastener Kit includes all the necessary nylon fasteners (screws, washers and nuts) plus marine silicone sealant for the installation of two access ports, also known as hatches, on to a catamaran like a Hobie, Nacra or Prindle. Use this page to order: 001-1159 White 001-1160 Black
    NYLON PORT FASTENER KIT
    Murrays Sports
    Prindle 16, P18 Jib Block Wire Murrays Part# 002-2224-00 Jib block wire for Prindle 16 or 18 is constructed to factory specifications. A swaging tool is needed for installation.
    PRINDLE 16/18 JIB BLOCK WIRE
    Murrays Sports
    6" Access Port with Lip Murrays Part# 001-4210WH The 6" Access Port with Lip is standard on the Hobie 18 and newer Prindle cats and it is an excellent upgrade for older Prindles. Ports can be installed on any flat deck, including kayaks, where there is 8-1/2" of flat surface available. These ports come with the inner lip so they are compatible with the 6"cat bag. Does not include hardware, hardware options shown in the related items section below. White port is Murrays #01-4210WH. Compare to Hobie Cat® #
    6" ACCESS PORT WITH LIP
    Sea Dog
    Prindle Shroud Anchor Bar Murrays Part# 56-1014 Shroud anchor bar for Prindle 15, 16 or 18 Performance Sports factory item# 1014
    PRINDLE SHROUD ANCHOR BAR
    NACRA
    Rudder Gudgeon Murrays Part# 56-1016 Rudder gudgeon for Prindle 15, 16 and 18 Nacra Sailing factory item# 30993
    NACRA RUDDER GUDGEON
    NACRA
    4" ALUMINUM BAR FOR BOW TANG Bow tang support rod for Prindle catamarans. Aluminum bar for bow tang on Prindle 15, 16 and 18 is Nacra Sailing factory item #30387.
    PRINDLE 4" ALUMINUM BAR FOR BOW TANG
    NACRA
    Bow Tang Murrays Part# 56-1810 Bow tang for Prindle 15, 16, 18 and Escape Nacra Sailing factory item# 30386
    PRINDLE/ESCAPE BOW TANG
    NACRA
    Prindle 15/16/18 Owner Manual Murrays Part# 56-9050 This is a copy of the original factory owner's manual for Prindle 15, 16 and 18 catamarans built by Performance Sports.
    PRINDLE 15/16/18 OWNER MANUAL
    Murrays Sports
    Prindle New Rubber Hull Plug Murrays Part# 56-1015 ​Solid rubber hull plug for Prindle's fits into 1-5/8″ diameter hole. This part is not as clean of a fit as the original part. Some silicone may help with placement. Nacra Sailing factory item #30378
    PRINDLE NEW RUBBER HULL PLUG
    NACRA
    Universal Drain Plug for most Hobie, Nacra and Prindle Catamarans which includes a gasket and fits most Hobie, Nacra and Prindle catamarans. Hobie part number 10091000
    Hobie drain plug 10091000 Hobie 18
    HOBIE DRAIN PLUG WITH GASKET
    Misc
    Screw PHMS 1/4-20 X 1" Stainless Steel Murrays Part# 19-3020 Stainless steel, slotted pan head 1/4-20 x 1" machine screw to fasten mast bearing on pre-1990 Hobie® 18. Other uses include universal Prindle/Nacra bow plate and bow tang on Prindle 15/16/18/Escape. Replaces Murrays item #56-F125.
    1/4-20 X 1" Stainless Steel Screw
    Misc
    Used for tiller connection on Hobie Cats®. The stainless 1/4-20 stainless steel hex nut with nylock insert will not rust or work loose if properly installed. Equivalent to Hobie #8050111. Also Equivalent to Nacra/Prindle F123 gudgon nut for all Prindle and older Nacras. Applications: Hobie 18 / H18: Bow Tang Nut Qty: 6 Rudder Adjustment: 1 Hobie Getaway: Forestay Yoke Nut
    NYLOCK NUT 1/4-20 SS
    Misc
    WASHER #8 (WH NYLON) Murrays PN 19-4006WH White nylon washer is used for installation of access ports (hatches).
    WASHER #8 WHITE NYLON
    Misc
    Cotter Pin 3/32 X 3/4 Murrays Part# 19-1015 Cotter pins are used on all Hobie, Nacra and Prindle rudder pins. They are used to secure the rudder pins. Compare to Hobie Cat® #8060111. Stainless steel cotter pin measures 3/32" x 3/4".
    COTTER PIN 3/32 X 3/4" SS
    Misc
